Perfect for: Road Bike Rider.
Tires: Designed to work with 700C*25C tire.
Cable routing: Internal cable routing.
Disc Brake: Flat mount disc brake mount
Groupset: Mechanical and Di2 groupset compatible
Material: High modulus carbon fiber
Item No :
R01-V700Cx25C Rim Brake Carbon Road Bike Frame
Product Specification:
| Frame | QTOUR Road Racing DIsc Brake Frame R01-V |
| Size | 470/500/530/560/580mm |
| Fork | QTOUR Carbon Fork F01-V |
| Headtube | Tapered 1 1/8-1 1/2'' Head Tube |
| Weight | 880±50g(Frame 470mm), 380mm±20g (Fork) |
| Bottom Bracket | BB86 Press Fit |
| Max Tire Clearance | 700C*25C |
| Brake Mount Type | Caliper Brake |
| Dropout | Frame: 130mm*φ10mm(QR), Fork: 100mm*φ9mm(QR) |
| Groupset | Shimano Ultegra Di2 R8050 |
| Test Standard | ISO4210 |
| Warranty | 2 Years |
